The fuel pump relay is an electromagnetic switch that uses low current to control a higher current circuit. Some common symptoms of a failing fuel pump include ignition issues, the fuel pump running continuously, and an illuminated check engine light. A fuel pump relay costs less than $20 for the part itself. Contentshide.. 6. Hold the multimeter probes against the other 2 prongs on the relay. Plug the multimeter probes into the ports on the bottom of the machine so you can use them for testing. Hold either of the probes against one of the prongs labeled with 30 or 87. Then press the second probe against the last prong on the relay.
